APPLICATIONS of FG7OHH2R
These cables are used as motor power supply cables with frequency converters where there is elegromagnetic interference exist. Generally used in industries like automotive, air conditining, packing, chemical and food. They can be used in dry, wet, oily and damp places inside under medium mechanical stress.
Voltage Rating: 0,6/1 kV (U0 / U)
Conductor: Electrolytic annealed, class 5 stranded plain copper wires (tinned conductor on request)
Insulation: Rubber based HEPR or equivalent compound, type G7 (EN 50363-0, CEI 20-11)
Inner Covering: Separating foil or PVC compound (PVC compound for 25 mm2 and above multi-core cables)
Screen 1: Al-Pes Tape (%100 covered)
Screen 2: Bare copper wire braiding (tinned wire on request)
Outer Sheath: Flame retardant PVC compound, Rz type (EN 50363-0, CEI 20-11)
Color: Light Grey or any other color
Operating Tempetature:
In Flexing Use: 0°C to +90°C
In Fixed Use: -15°C to +90°C
Conductor Short-Circuit Temp: 250°C (Max. 5 sec.)
Min. Installation Temp.: 0°C
Min. Bending Radius: CEI UNEL 35375,CEI UNEL 35377
| Cross (*) Section (mm2) | Nominal Overall Diameter (mm) | Approximate Weight (kg / km) | Min.Bending Radius (fixed installation) (mm) | Max. Resistance of Conductors at 20°C (ohm / km) |
| 3×1,5/1,5 | 10,60 | 146 | 85 | 13,30 |
| 3×2,5/2,5 | 11,60 | 191 | 93 | 7,98 |
| 3×4/4 | 12,80 | 265 | 102 | 4,95 |
| 3×6/6 | 14,70 | 356 | 118 | 3,30 |
| 3×10/10 | 17,30 | 545 | 138 | 1,91 |
| 3×16/16 | 19,50 | 780 | 156 | 1,21 |
| 3×25/16 | 25,80 | 1385 | 206 | 0,78 |
| 3×35/16 | 27,70 | 1671 | 222 | 0,554 |
| 3×50/25 | 32,00 | 2350 | 256 | 0,386 |
| 3×70/35 | 37,60 | 3355 | 301 | 0,272 |
| 3×95/50 | 41,40 | 4310 | 331 | 0,206 |
| 3×120/70 | 46,60 | 5530 | 373 | 0,161 |
| 3×150/95 | 51,10 | 6946 | 409 | 0,129 |
| 3×185/95 | 56,80 | 8275 | 454 | 0,106 |
| 3×240/120 | 63,90 | 10755 | 511 | 0,0801 |
