Used in energy networks refineries, mines, hotels, schools, tunnels, high constructions, hospitals, power plants, data processing centers, business centers where there is a risk of fire
Conductor material ：Copper
Fire proof: Mica tape
Conductor shape：Circular stranded (RM)
Insulation：XLPE (Cross-linked Polyethylene)
Outer sheath : LSZH
Halogen free : IEC60754-1
Armour type : Steel wires
Sheath colour : Orange
Rated Voltage Uo/U (Um): 0,6/1 kV
Usage characteristics：
Operating temperature, range: -20 … 60 °C
Short-circuit max. conductor temperature: 250 °C
Flame retardant: IEC 60332-3 Cat. C
Smoke density: IEC 61034
Gases corrosivity: IEC 60754-2
Fire resistant : IEC 60331-21
Max. conductor temperature in service：90 °C
| Name | Number of cores |
| N2XRH FE 180 2×1.5 mm2 | 2 |
| N2XRH FE 180 2×2.5 mm2 | 2 |
| N2XRH FE 180 2×4 mm2 | 2 |
| N2XRH FE 180 2×6 mm2 | 2 |
| N2XRH FE 180 2×10 mm2 | 2 |
| N2XRH FE 180 2×16 mm2 | 2 |
| N2XRH FE 180 2×25 mm2 | 2 |
| N2XRH FE 180 2×35 mm2 | 2 |
| N2XRH FE 180 2×50 mm2 | 2 |
| N2XRH FE 180 2×70 mm2 | 2 |
| N2XRH FE 180 2×95 mm2 | 2 |
| N2XRH FE 180 2×120 mm2 | 2 |
| N2XRH FE 180 2×150 mm2 | 2 |
| N2XRH FE 180 2×185 mm2 | 2 |
| N2XRH FE 180 2×240 mm2 | 2 |
| N2XRH FE 180 3×1.5 mm2 | 3 |
| N2XRH FE 180 3×2.5 mm2 | 3 |
| N2XRH FE 180 3×4 mm2 | 3 |
| N2XRH FE 180 3×6 mm2 | 3 |
| N2XRH FE 180 3×10 mm2 | 3 |
| N2XRH FE 180 3×16 mm2 | 3 |
| N2XRH FE 180 3×25 mm2 | 3 |
| N2XRH FE 180 3×35 mm2 | 3 |
| N2XRH FE 180 3×50 mm2 | 3 |
| N2XRH FE 180 3×70 mm2 | 3 |
| N2XRH FE 180 3×95 mm2 | 3 |
| N2XRH FE 180 3×120 mm2 | 3 |
| N2XRH FE 180 3×150 mm2 | 3 |
| N2XRH FE 180 3×185 mm2 | 3 |
| N2XRH FE 180 3×240 mm2 | 3 |
| N2XRH FE 180 4×1.5 mm2 | 4 |
| N2XRH FE 180 4×2.5 mm2 | 4 |
| N2XRH FE 180 4×4 mm2 | 4 |
| N2XRH FE 180 4×6 mm2 | 4 |
| N2XRH FE 180 4×10 mm2 | 4 |
| N2XRH FE 180 4×16 mm2 | 4 |
| N2XRH FE 180 4×16 mm2 | 4 |
| N2XRH FE 180 4×25 mm2 | 4 |
| N2XRH FE 180 4×35 mm2 | 4 |
| N2XRH FE 180 4×50 mm2 | 4 |
| N2XRH FE 180 4×70 mm2 | 4 |
| N2XRH FE 180 4×95 mm2 | 4 |
| N2XRH FE 180 4×120 mm2 | 4 |
| N2XRH FE 180 4×150 mm2 | 4 |
| N2XRH FE 180 4×185 mm2 | 4 |
| N2XRH FE 180 4×240 mm2 | 4 |
| N2XRH FE 180 4×300 mm2 | 4 |
| N2XRH FE 180 5G1.5 mm2 | 5 |
| N2XRH FE 180 5G2.5 mm2 | 5 |
| N2XRH FE 180 5G4 mm2 | 5 |
| N2XRH FE 180 5G6 mm2 | 5 |
| N2XRH FE 180 5G10 mm2 | 5 |
| N2XRH FE 180 5G16 mm2 | 5 |
| N2XRH FE 180 5G25 mm2 | 5 |
| N2XRH FE 180 5G35 mm2 | 5 |
| N2XRH FE 180 5G50 mm2 | 5 |
| N2XRH FE 180 5G70 mm2 | 5 |
