Application
These cables are designed to withstand extreme environments of severe abrasion, cutting, and tearing, suitable for powering mobile machinery and equipment in dry, wet, and submerged conditions. They are commonly used in underground and open-pit mines, tunnel equipment, crane systems, and heavy-duty trolley systems.
Voltage Rating Uo/U (Um): 0.6/1 kV
Minimum Bending Radius: Mobile use: 10 x overall diameter
Conductor: Class 6 Flexible Tinned Copper Conductor
Insulation: EPR (Ethylene Propylene Rubber)
Monitoring Cores (Optional): Special conductor + Tinned copper braid + Galvanized steel wire braid
Inner Sheath: GM1b Rubber
Armour / Earth Conductor: Copper-steel composite wire braid (Concentric copper-steel composite wire braid)
Outer Sheath: 5GM5 Chlorinated Rubber (Abrasion-resistant, tear-resistant, oil-resistant, flame-retardant)
| Cross-section | MIN. OVERALL DIAMETER | MAX. OVERALL DIAMETER | APPROX. CABLE WEIGHT | COPPER WEIGHT |
| (mm²) | (mm) | (mm) | (kg/km) | (kg/km) |
| 3×25+3×25/3 | 40 | 44 | 2470 | 960 |
| 3×35+3×25/3 | 44.4 | 48.4 | 3150 | 1.344 |
| 3×95+3×50/3 | 59.9 | 63.9 | 6210 | 3.216 |
| 3×120+3×70/3 | 63.8 | 67.8 | 7430 | 4.128 |
| 3×150+3×70/3 | 69.2 | 73.2 | 8900 | 4.992 |
| 3×185+3×95/3 | 73.1 | 77.1 | 10330 | 6.24 |
