APPLICATION of ARG16R16
In earth, ducts, on support brackets, in dry and wet conditions etc., where one does not expect mechanical damages and the cables are not exposed to the mechanical tensile strain. In urban networks, industrial plants, electric power plants and other electricity consumers and for connection of control devices in industry, traffic etc., where fire prevention safety measures are requested, for eleveted electricity and thermic strains.
Rated voltage: 0,6/1 kV
Conductors: Al, class 2 according to EN 60228
Insulation: XLPE compound
Bedding: Extruded elastomere or plastomere LS0H compound
Sheath: PVC compound R16 quality, gray
Outer Sheath Colour: Grey; Other colours available on request
Bending radius (min): single-core – 15D
Min. laying temperature: -15°C
Max. conductor temperature: 90°C
Max. short-circuit temperature: 250°C
STANDARD: CEI 20-13
| CROSS SECTION | INSULATION THICKNESS | SHEATH THICKNESS | OUTER DIAM (APPROX.) | CABLE WEIGHT (APPROX.) |
| mm² | mm | mm | mm | kg/km |
| 1×16 | 0,7 | 1,4 | 10,0 | 150 |
| 1×25 | 0,9 | 1,4 | 11,7 | 185 |
| 1×35 | 0,9 | 1,4 | 13,0 | 220 |
| 1×50 | 1,0 | 1,4 | 14,7 | 280 |
| 1×70 | 1,1 | 1,4 | 16,6 | 320 |
| 1×95 | 1,1 | 1,5 | 18,6 | 460 |
| 1×120 | 1,2 | 1,5 | 20,5 | 570 |
| 1×150 | 1,4 | 1,6 | 22,8 | 670 |
| 1×185 | 1,6 | 1,6 | 25,0 | 810 |
| 1×240 | 1,7 | 1,7 | 27,9 | 1025 |
| 1×300 | 1,8 | 1,8 | 30,7 | 1205 |
| 1×400 | 2,0 | 1,9 | 35,0 | 1660 |
| 1×500 | 2,2 | 2,0 | 38,6 | 1940 |
| 1×630 | 2,4 | 2,2 | 43,1 | 2460 |
