Applications
These armoured fire performance power cables are fire resistant and designed for direct impact. Designed to meet the application of fire, direct impact and water jet as specified in BS 8491, making them suitable for use as 120 minute rated category 3 power cables according to BS 8519.
Voltage Rating Uo/U: 0.6/1kV
Operating Temperature: -20ºC to +90ºC
Conductor: Class 2 stranded copper
Fire Barrier: MGT (Mica Glass Tape)
Insulation: XLPE (Cross-Linked Polyethylene)
Inner Barrier: Glass Tape
Bedding: LSZH (Low Smoke Zero Halogen)
Armour: SWA (Galvanised Steel Wire Armour)
Outer Barrier: Glass Tape
Sheath: LSZH (Low Smoke Zero Halogen)
Sheath Colour: Black
| NO. OF CORES | NOMINAL CROSS SECTIONAL AREA | NOMINAL WEIGHT |
| mm² | kg/km | |
| 2 | 4 | 950 |
| 2 | 6 | 1100 |
| 2 | 10 | 1200 |
| 2 | 16 | 1400 |
| 2 | 25 | 1800 |
| 2 | 35 | 2250 |
| 3 | 4 | 950 |
| 3 | 6 | 1100 |
| 3 | 10 | 1200 |
| 3 | 16 | 1500 |
| 3 | 25 | 2000 |
| 3 | 35 | 2500 |
| 3 | 50 | 2750 |
| 3 | 70 | 3500 |
| 3 | 95 | 4750 |
| 3 | 120 | 5500 |
| 3 | 150 | 7000 |
| 3 | 185 | 8250 |
| 3 | 240 | 10500 |
| 3 | 300 | 12500 |
| 3 | 400 | 15500 |
| 4 | 4 | 1100 |
| 4 | 6 | 1200 |
| 4 | 10 | 1500 |
| 4 | 16 | 1700 |
| 4 | 25 | 2500 |
| 4 | 35 | 3000 |
| 4 | 50 | 3250 |
| 4 | 70 | 4500 |
| 4 | 95 | 5750 |
| 4 | 120 | 7250 |
| 4 | 150 | 8500 |
| 4 | 185 | 10500 |
| 4 | 240 | 13000 |
| 4 | 300 | 16000 |
| 4 | 400 | 21000 |
| 5 | 4 | 1200 |
| 5 | 6 | 1400 |
| 5 | 10 | 1700 |
| 5 | 16 | 2250 |
