Category Conductor Description: Bare, annealed copper conforming to ASTM B3 and Stranded in accordance with ASTM B8 (Class B);
Category Insulation Description: Flame-retardant Polyvinyl Chloride (PVC) and nylon covering, rated 90°C; C per UL Standard 83 Color Code: ICEA Method 1;
Overall Shield: Aluminum/polyester tape shield providing 100% coverage Stranded tinned copper drain wire, same size as insulated conductors;
Inner Jacket: Flame retardant Polyvinyl Chloride (PVC) per UL 1569, Black Low temp performance meets ASTM D746 brittleness temp at or below -40°C Nylon ripcord;
Armor: Impervious, continuously corrugated and welded aluminum per UL 1569 & 2225 Meets grounding requirements of NEC Article 250;
Overall Jacket: Flame-retardant, moisture and sunlight resistant Polyvinyl Chloride (PVC) per UL Standards 1569, black Low temperature performance meets ASTM D746 brittleness temperature at or below -40°C
Category Conductor Description: Bare, annealed copper conforming to ASTM B3 and stranded in accordance with ASTM B8 (Class B);
Category Insulation Description: Flame-retardant Polyvinyl Chloride (PVC) insulation and nylon covering, rated 90°C per UL Standard 83 Color Code: ICEA Method 1;
Individual Shield: Isolated and individually twisted pairs or triads with an aluminum/polyester tape shield providing 100% coverage Drain wire;
Overall Shield: Aluminum/polyester tape shield providing 100% coverage Drain wire;
Inner Jacket: Flame retardant Polyvinyl Chloride (PVC) per UL 1569, black Low temp performance meets ASTM D746 brttleness temp at or below -40°C Nylon ripcord;
Armor:Impervious, continuously corrugated and welded aluminum per UL 1569 & 2225 Meets grounding requirements of NEC Article 259;
Overall Jacket: Flame-retardant, moisture and sunlight resistant Polyvinyl Chloride (PVC) per UL Standards 1569, black Low temperature performance meets ASTM D746 brittleness temperature at or below -40°C
Category Conductor Description: Bare, annealed copper conforming to ASTM B-3 and stranded in accordance with ASTM B8 (Class B)
Category Insulation Description: Flame-retardant Polyvinyl Chloride (PVC) and nylon covering, rated 105°C per UL Standard 13 & 2250 Color Code: ICEA Method 1
Individual Shield: Aluminum/polyester tape with 100% coverage Drain wire
Overall Shield: Aluminum/polyester tape shield providing 100% coverage Drain wire
Inner Jacket: Flame-retardant Polyvinyl Chloride (PVC) per UL Standards 13 and 2250 Low temperature performance meets ASTM D746 brittleness temperature at or below 40°C Nylon rip cord to facilitate jacket removal
Armor: Impervious, continuously corrugated and welded aluminum per UL 1569 Meets grounding requirements of NEC Article 250
Overall Jacket: Flame-retardant, moisture and sunlight resistant Polyvinyl Chloride (PVC) per UL Standards 13 and 2250 Low temperature performance meets ASTM D746 brittleness temperature at or below -40°C
Category Conductor Description: Bare, annealed copper conforming to ASTM B-3 and stranded in accordance with ASTM B8 (Class B)
Category Insulation Description: Flame-retardant Polyvinyl Chloride (PVC), rated 105°C per UL Standard 13 & 2250 Color Code: ICEA Method 1
Shield: UL Type PLTC and ITC-HL UL 13, 2250, 1569, 1309, and 1581 IEEE 383 and 1202
Inner Jacket: Flame-retardant Polyvinyl Chloride (PVC) per UL Standards 13 and 2250 Low temperature performance meets ASTM D746 brittleness temperature at or below 40°C Nylon rip cord to facilitate jacket removal
Armor: Impervious, continuously corrugated and welded aluminum per UL 1569 Meets grounding requirements of NEC Article 250
Overall Jacket: Flame-retardant, moisture and sunlight resistant Polyvinyl Chloride (PVC) per UL Standards 13 and 2250 Low temperature performance meets ASTM D746 brittleness temperature at or below -40°C Nylon ripcord
