APPLICATION
Suitable for the strictest safety requirements in case of fire, such as: emergency lightings, alarm and automatic fire detection systems, fire extinguishing systems, automatic emergency exits, lift systems, activation of smoke outlets or shutters, fans, air conditioning, and telephone and videosurveillance systems.
Voltage Rating: 300/500 V
Temperature Rating Operating: -15°C to +90°C
Maximum temperature of short circuit: +350°C
Minimum Bending Radius: 6 x overall diameter
CONSTRUCTION:
Conductor: Up to 6mm2 : Class 1 solid copper; 10mm2 and above: Class 2 stranded copper
Insulation: Fire resistant silicone rubber
Sheath: LSZH (Low smoke zero halogen) Thermoplastic M1
Sheath Colour: Orange
STANDARDS
IEC/ NF EN 60228, NF C 32-310, IEC/NF EN
60754-1/2, IEC/NF EN 61034-2
Fire resistance CR1 according to NF C 32-070
Flame retardant C1 according to NF C 32-070
| NO. OF CORES | NOMINAL CROSS SECTIONAL AREA mm² | CLASS OF CONDUCTOR | NOMINAL WEIGHT kg/km |
| 1 | 1.5 | 1 | 35 |
| 1 | 2.5 | 1 | 50 |
| 1 | 4 | 1 | 70 |
| 1 | 6 | 2 | 90 |
| 1 | 10 | 2 | 155 |
| 1 | 16 | 2 | 215 |
| 1 | 25 | 2 | 320 |
| 1 | 35 | 2 | 430 |
| 1 | 50 | 2 | 565 |
| 1 | 70 | 2 | 800 |
| 1 | 95 | 2 | 1070 |
| 1 | 120 | 2 | 1335 |
| 1 | 150 | 2 | 1640 |
| 1 | 185 | 2 | 2065 |
| 1 | 240 | 2 | 2710 |
| 1 | 300 | 2 | 3360 |
| 2 | 1.5 | 1 | 70 |
| 2 | 2.5 | 1 | 105 |
| 2 | 4 | 1 | 140 |
| 2 | 6 | 1 | 185 |
| 2 | 10 | 2 | 325 |
| 2 | 16 | 2 | 455 |
| 2 | 25 | 2 | 680 |
| 2 | 35 | 2 | 920 |
| 2 | 50 | 2 | 1230 |
| 2 | 70 | 2 | 1720 |
| 2 | 95 | 2 | 2280 |
| 3 | 10 | 2 | 455 |
| 3 | 16 | 2 | 650 |
| 3 | 25 | 2 | 970 |
| 3 | 35 | 2 | 1325 |
| 3 | 50 | 2 | 1760 |
| 3 | 70 | 2 | 2475 |
| 3 | 95 | 2 | 3300 |
| 4 | 1.5 | 1 | 125 |
| 4 | 2.5 | 1 | 180 |
| 4 | 4 | 1 | 250 |
| 4 | 6 | 1 | 340 |
| 4 | 10 | 2 | 590 |
| 4 | 16 | 2 | 855 |
| 4 | 25 | 2 | 1275 |
| 4 | 35 | 2 | 1735 |
| 5 | 2.5 | 1 | 215 |
| 5 | 4 | 1 | 305 |
| 5 | 6 | 1 | 420 |
| 5 | 10 | 2 | 735 |
| 5 | 16 | 2 | 1055 |
| 5 | 25 | 2 | 1580 |
| 5 | 35 | 2 | 2145 |
| 5 | 50 | 2 | 2855 |
| 5 | 70 | 2 | 4035 |
| 5 | 95 | 2 | 5380 |
| 6 | 1.5 | 1 | 170 |
| 6 | 2.5 | 1 | 250 |
| 7 | 1.5 | 1 | 200 |
| 7 | 2.5 | 1 | 295 |
