Applications
H05Z-K / H07Z-K LSZH cables for appliances with maximum operating temperatures of 90°C, and generally in areas (such as public and government buildings) where smoke and toxic fumes may
cause a threat to life and equipment. The cables produce no corrosive gases when burnt which is particularly important where electronic equipment is installed.
Voltage Rating Uo/U:
H05Z-K – 0.5mm² to 1mm²: 300/500V
H07Z-K – 1.5mm² to 240mm²: 450/750V
Temperature Rating: -25°C to +90°C
Conductor: Class 5 flexible copper conductor
Insulation: LSZH (Low Smoke Zero Halogen)
Insulation Colour:
Red Black Blue Orange White Yellow
Green/Yellow Grey Brown Violet Pink
| NOMINAL CROSS SECTIONAL AREA | NOMINAL THICKNESS OF INSULATION | NOMINAL WEIGHT |
| mm2 | mm | kg/km |
| 0.5 | 0.6 | 8.7 |
| 0.75 | 0.6 | 11.3 |
| 1 | 0.6 | 13.9 |
| 1.5 | 0.7 | 19.3 |
| 2.5 | 0.8 | 30.9 |
| 4 | 0.8 | 44.9 |
| 6 | 0.8 | 64.2 |
| 10 | 1 | 108.2 |
| 16 | 1 | 163.4 |
| 25 | 1.2 | 248.1 |
| 35 | 1.2 | 340.6 |
| 50 | 1.4 | 484.2 |
| 70 | 1.4 | 671 |
| 95 | 1.6 | 895.8 |
| 120 | 1.6 | 111.1 |
| 150 | 1.8 | 1389.2 |
| 185 | 2 | 1724.1 |
| 240 | 2.2 | 2225.4 |
