Applications
Used as an indoor general wiring cable primarily for installations in public areas. Examples include use on pendant lighting drops or as a general supply lead within hospital or airport projects. For installation where fire, smoke emission and toxic fumes create a potential risk to life and equipment.
Voltage Rating (Uo/U): 300/500V
Temperature Rating: +5°C to +70°C
Conductor: Class 5 flexible copper conductor
Insulation: LSZH (Low Smoke Zero Halogen) Type TI6
Sheath: LSZH (Low Smoke Zero Halogen) Type TM7
| NO. OF CORES | NOMINAL CROSS SECTIONAL AREA | NOMINAL WEIGHT |
| mm2 | kg/km | |
| 2 | 0.75 | 57 |
| 2 | 1 | 65 |
| 2 | 1.5 | 84 |
| 2 | 2.5 | 130 |
| 2 | 4 | 180 |
| 3 | 0.75 | 68 |
| 3 | 1 | 78 |
| 3 | 1.5 | 107 |
| 3 | 2.5 | 163 |
| 3 | 4 | 212 |
| 4 | 0.75 | 83 |
| 4 | 1 | 100 |
| 4 | 1.5 | 134 |
| 4 | 2.5 | 201 |
| 4 | 4 | 290 |
| 5 | 0.75 | 103 |
| 5 | 1 | 130 |
| 5 | 1.5 | 170 |
| 5 | 2.5 | 255 |
| 5 | 4 | 360 |
