Applications
High-performance, high temperature power cable used principally within the Automation and Process Control industry. This cable is designed to operate under more arduous high temperature conditions, providing moisture resistance, toughness, flexibility and a continuous conductor operating temperature of 250ºC.
Voltage Rating Uo/U: 0.6/1kV
Temperature Rating Fixed: -75ºC to +250°C
Conductor: Class 5 flexible nickel-plated copper conductor
Insulation: PFA (Perfluoroalkoxy)
Separator: Mica tape
Sheath: Glass fibre braid with a heat resistant varnish
Sheath Colour: Natural
STANDARDS:
Generally to Specification for PTFE insulated equipment wire
BS G210
| NO. OF CORES | NOMINAL CROSS SECTIONAL AREA | NOMINAL WEIGHT |
| mm² | kg/km | |
| 1 | 1 | 24 |
| 1 | 1.5 | 29 |
| 1 | 2.5 | 39 |
| 1 | 4 | 54 |
| 1 | 6 | 97 |
| 1 | 10 | 141 |
| 1 | 16 | 197 |
