Cables for Medical Applications
Huadong Cable Group produces custom cables for use in a wide range of medical technology devices. Whether robot cables, cables for intravascular imaging systems, cleanroom cables, control cables or silicone cables, at Huadong Cable Group you will find the right cable for every sensitive and demanding area of medical technology. Whether you need a reusable or single-use solution, your medical cable will meet quality and safety connectivity standards. Huadong Cable Group is Quality Management System certified to ISO 9001:2015 and ISO 13485:2016.
Voltage: 1500V
Conductor: galvanized copper wire
Insulation: silicone rubber
Shield: aluminum foil with conductive side facing drain wire
Sheath: silicone rubber
Voltage: up to 900 V
Temperature range: -40°C/+100°C
Conductor: finely-stranded, silver-plated copper
Insulation: FEP
Stranding: highest precise, homogenized stranding
Screen: highly-efficient tinned copper braid
Sheath material: Customized to your needs
Cleaning: standard whipe disinfection, ETO
Surface: “non-sticky“
Harness: upgraded for individual connectors
Voltage: up to 900 V
Temperature range: -40°C/+100°C
Conductor: finely-stranded, silver-plated copper
Insulation: FEP
Screen: highly-efficient tinned copper braid
Sheath material: Customized to your needs
Cleaning: autoclavable, standard whipe disinfection
Surface: “non-sticky“
Application: permanent bending and torsion
Voltage: up to 900 V
Temperature range: -40°C/+100°C
Conductor: finely-stranded, silver-plated copper
Insulation: FEP
Screen: highly-efficient tinned copper braid
Sheath material: Customized to your needs
Cleaning: autoclavable, standard whipe disinfection
Surface: “non-sticky“
Application: permanent bending and torsion
Voltage: up to 50 V
Temperature range: -40°C/+180°C
Testing voltage: selection test acc. to 2 MOP
Conductor: finely-stranded, silver-plated copper
Insulation: FEP
Screen: highly-efficient tinned copper braid
Cleaning: autoclavable, standard whipe disinfection
Surface: “non-sticky“
Voltage: up to 375 V
Temperature range: -40°C/+80°C
Testing voltage: selection test acc. to 2 MOP
Conductor: finely-stranded conductor
Stranding: hybrid combination with different tubes
Screen: highly-efficient tinned or silver copper braid
Sheath material: PU
Cleaning: standard whipe disinfection
Surface: “non-sticky“
Application: mechanical sophisticated, cross-pressure stable
