Applications
Power cables, indoor use also in wet environments, outdoor installation, fixed laying on bare walls or steel structures, in pipes or in underground. UV resistant, suitable for permanent external use. Cables suitable for electrical power systems in constructions and other civil engineering buildings. CPR compliant. Also used for control and signalling applications.
Voltage Rating: 0.6/1kV
Temperature Rating Operating: -15°C to +70°C
Maximum temperature of short circuit: +160°C
Conductor: Class 5 flexible copper conductor
Insulation: PVC (Polyvinyl Chloride)
Screen: Copper Tape
Sheath: PVC (Polyvinyl Chloride)
Core Identification:
2 core: Blue Brown
3 core: Green/Yellow Blue Brown
4 core: Green/Yellow Brown Black Grey
5 core: Green/Yellow Brown Black Grey Blue
7 cores and above: Black with Numbers plus Green/Yellow
Sheath Colour: Blue
STANDARDS:
CEI 20-13, IEC 60502-1, CEI EN 60228, EN 50575
Flame Retardant according to EN 60332-1-2
| NO. OF CORES | NOMINAL CROSS SECTIONAL AREA mm2 | NOMINAL WEIGHT kg/km |
| 2 | 1.5 | 240 |
| 2 | 2.5 | 280 |
| 2 | 4 | 380 |
| 2 | 6 | 480 |
| 2 | 10 | 640 |
| 2 | 16 | 810 |
| 2 | 25 | 1130 |
| 2 | 35 | 1430 |
| 2 | 50 | 1980 |
| 2 | 70 | 2660 |
| 2 | 95 | 3350 |
| 3 | 1.5 | 260 |
| 3 | 2.5 | 320 |
| 3 | 4 | 430 |
| 3 | 6 | 550 |
| 3 | 10 | 740 |
| 3 | 16 | 970 |
| 3 | 25 | 1340 |
| 3 | 35 | 1750 |
| 3 | 50 | 2400 |
| 3 | 70 | 3270 |
| 3 | 95 | 4170 |
| 3 | 120 | 4670 |
| 3 | 185 | 5700 |
| 3 | 240 | 6300 |
| 3+1 | 35+25 | 2000 |
| 3+1 | 50+25 | 2620 |
| 3+1 | 70+35 | 3560 |
| 3+1 | 95+50 | 4600 |
| 4 | 1.5 | 300 |
| 4 | 2.5 | 370 |
| 4 | 4 | 530 |
| 4 | 6 | 650 |
| 4 | 10 | 910 |
| 4 | 16 | 990 |
| 4 | 25 | 1350 |
| 5 | 1.5 | 350 |
| 5 | 2.5 | 410 |
| 5 | 4 | 590 |
| 5 | 6 | 740 |
| 5 | 10 | 1060 |
| 5 | 16 | 1390 |
| 5 | 25 | 2030 |
| 7 | 1.5 | 400 |
| 7 | 2.5 | 530 |
| 10 | 1.5 | 530 |
| 10 | 2.5 | 670 |
| 12 | 1.5 | 590 |
| 12 | 2.5 | 760 |
| 16 | 2.5 | 950 |
| 19 | 1.5 | 820 |
| 27 | 1.5 | 1070 |
| 37 | 1.5 | 1360 |
