Single Core & 2 Core PV1-F DC Solar Cable

Application and performance

TUV PV1-F Solar Cable is specialized components used in Solar power system to connect solar panel and Inverter or controller box. They’re UV resistance and can be working outdoor in extreme environments,Ozone,Hydrolysis resistant for 25years.

Single Core PV1-F Solar Cable

Voltage : AC: 1000/1000V, DC: 1500/1500V
Conductor: 99.99% Strand Tinned Copper Wire.
Insulation: XLPO, Halogen-free.
Jacket: XLPO, Halogen-free, UV resistant.
Size: 1×2.5mm,1x4mm,1x6mm,1x10mm,1x16mm
Standard : TUV 2PfG 1169 PV1-F
Temperature: -40℃~120℃
Color: Black , Red

2 Core 1000V PV1-F Solar Cable

Conductor: Tinned copper, according to the VDE0295/IEC60228,Class 5
Insulation: XLPO
Outer sheath: XLPO
Size: 2×2.5mm,2x4mm,2x6mm,2x10mm
Standard : TUV 2PfG 1169 PV1-F
Voltage : 600V/1000V AC,1000/1800V DC
Temperature: -40℃~120℃

Single Core PV1-F Solar Cable

Size	Conductor Constuction	Conductor OD	Cable OD	Resistance Max.	Rated Voltage	60℃ Ampacity
mm2	n x mm	mm	mm	Ω/Km	V	A
1×1.5	30×0.25	1.58	4.9	13.7	1000/1800	30
1×2.5	48×0.25	2.02	5.45	8.21	1000/1800	41
1×4.0	56×0.3	2.35	6.1	5.09	1000/1800	55
1×6.0	84×0.3	3.2	7.2	3.39	1000/1800	70
1×10	142×0.3	4.6	9	1.95	1000/1800	98
1×16	228×0.3	5.6	10.2	1.24	1000/1800	132
1×25	361×0.3	6.95	12	0.795	1000/1800	176
1×35	494×0.3	8.3	13.8	0.565	1000/1800	218

sales@huadongcablegroup.com

2 Core 1000V PV1-F Solar Cable

Size	Conductor Constuction	Conductor OD	Cable OD	Resistance Max.	Rated Voltage	60℃ Ampacity
mm2	n x mm	mm	mm	Ω/Km	V	A
2×2.5	48×0.25	2.02	5.45×11.0	8.21	1000/1800	41
2×4.0	56×0.3	2.35	6.10×12.3	5.09	1000/1800	55
2×6.0	84×0.3	3.2	7.20×14.5	3.39	1000/1800	70
2×10	142×0.3	4.6	9.00×18.1	1.95	1000/1800	98
