Types of rubber cable: Trailing/Reeling/Festoon/ Neoprene, CPE, EPR, TPU Rubber Cable for Mining/Crane Mobile Equipment, PNCT Cable, H05RR-F, H07RN-F, H07ZZ-F, Welding cable, H01N2-D, NSHXAFO, NSGAFOU, H07N8-F, SJ/SJO/SJOOW/SOOW Resistance oil rubber cable, mining rubber cable,PVC/PVC Insulated flexible Cable.
We are manufacturer, founded in 1999 and can directly customize the rubber flexible cable you need
Hot Sales Rubber Cable:
1-8 Core 3PNCT, 2PNCT-F/R 2PNCT-H/ 2PNCT-H-U PNCT Rubber Cable
Product Feature:
Voltage: 0.6/1kv
Color: Black or by request.
Conductor: Flexible Copper/Tinned Copper
Insulation: Rubber/EPR
...
Voltage: 0.6/1kv
Color: Black or by request.
Conductor: Flexible Copper/Tinned Copper
Insulation: Rubber/EPR
...
1.5mm ~ 630mm H07RN-F/ H05RN-F Flexible Rubber Cable
H07RN-F flexible rubber cable, Heavy, HAR, oil-resistant and flame-retardant Rated voltage Uo/U: 450/750V
Conductor: Class ...
Conductor: Class ...
10-120mm2 Flexible PVC/Rubber H01N1-D Welding & Battery Cable
Welding & Battery Cable Construction Conductor : Flexible bare annealed copper wire or tinned copper ...
SJ/SJOOW/SJO/SOOW/SO/SEOOW Resistance Oil Rubber Cable With UL62 Certification
Description: 1. Insulation: Ethylene Propylene Diene Monomer (EPDM) or EP compound
2. Jacket: rubber or ...
2. Jacket: rubber or ...
Recommended common rubber cables for large machinery
(N)TSCGEWÖU Cable for Material Handling Equipment
- Voltage: 1.8/3kV, 3. 6/6kV, 6/10kV, 8. 7/15kV, 12/ 20 kV
- Phase/Earth Conductor: Class 5 flexible tinned copper/Copper
- Insulation: Rubber compound
- Inner Sheath: Rubber compound
- Section area: 25-185mm2
- Cores: 3+3
- Application: Flexible cable for fixed distribution lines in mines and alongside material handling equipment. Suitable for indoor and outdoor applications
PUR-HF Low Voltage Chain Festoon Cable
- Voltage: 0.6/1kV
- Conductor: Class 5 flexible tinned copper
- Insulation: HF (Halogen Free) compound based on polyester
- Outer Sheath: TPU, PUR HFFR (Polyurethane – Halogen Free, Flame Retardant)
- Cores: 3,4,5
- Section aera: 1.5mm2-185mm2
- Application: For use as energy and control cable in festoon systems and as a chain cable.
PUR/TPU Spreader LV Reeling Cable
- Voltage: 0.6/1kV
- Conductor: Class 5 flexible tinned copper
- Insulation: Halogen free compound based on polyester
- Inner and Outer Sheath: TPU, PUR-HF (Halogen Free, flame retardant Polyurethane)
- Braiding: Anti-twisting element – Aramid yarns braiding
- Sheath Colour: Black, Yellow or Orange.
- Application: Mainly used for spreader reeling applications. Strength member to increase tensile load, acceleration and speed
JHS Waterproof Flat and Round Type Submersible Pump Cable
- Voltage: 300/500V, 450/750V, 600/1000V
- Type: Flat/Round or twisted
- Conductor Working temperature: 85°C
- Insulation: EPR/PVC/Rubber
- Application: This cable is suitable for various types of the lead wire of submersible motor.
Round and Flat type Trailing Rubber Cable
- Voltage: 3.3kv, 6/10Kv
- Conductor: Class 5,6 flexible copper
- Insulation: EPR
- Outer Sheat: EPR
- Cores: 3+3 Core, 6 Cores
- Application: it is for use oncable reel system on material handling equipment(i.e. Stacker/reclaimer, STS, RMG).
LV Round EPR/PUR Reeling Cable-(NSHTOEU)
- Voltage: 0.6/1kV
- Conductor: Tinned copper flexible class 5
- Insulation: EPR(3GI3)
- Core identification: Up to 5 cores, From 6 cores: black with white numbers
- Core arrangement: Central filler, plastic or textile, if necessary covered with rubber.
- Inner Sheath: EPR rubber (5GM3)
- Reinforcement: Wide-meshed polyester braid, embedded in the sheath
- Outer Sheath: PCP / PUR (5GM5)
- Marking: NSHTOEU-J (number of cores) x (cross-section)
- Application: Flexible low-voltage reeling cable for application under medium mechanical stresses.
