Applications
Halogen-free screened flexible connecting cables for use in mechanical engineering for instrumentation and control equipment and for tooling machinery production lines. Suitable for flexible applications for free movement without tensile load, in dry, moist and wet rooms. The screen protects against external interference pulses whilst the bedding provides additional mechanical protection. These cables are not used for outdoor or underground installation.
Rated Voltage Uo/U: 300/500V
Conductor: Class 5 flexible stranded plain copper
Insulation: LSZH (Low Smoke Zero Halogen)
Bedding: LSZH (Low Smoke Zero Halogen)
Screen: TCWB (Tinned Copper Wires Braid)
Sheath: LSZH (Low Smoke Zero Halogen)
Sheath Colour: Grey
| NO. OF CORES | NOMINAL CROSS SECTIONAL AREA | NOMINAL WEIGHT |
| mm2 | kg/km | |
| 2 | 0.5 | 77 |
| 2 | 0.75 | 77 |
| 2 | 1 | 107 |
| 2 | 1.5 | 127 |
| 3 | 0.5 | 89 |
| 3 | 0.75 | 106 |
| 3 | 1 | 120 |
| 3 | 1.5 | 152 |
| 3 | 2.5 | 243 |
| 4 | 0.5 | 105 |
| 4 | 0.75 | 123 |
| 4 | 1 | 142 |
| 4 | 1.5 | 178 |
| 4 | 2.5 | 254 |
| 4 | 4 | 371 |
| 4 | 6 | 489 |
| 4 | 10 | 766 |
| 4 | 16 | 1062 |
| 4 | 25 | 1577 |
| 4 | 35 | 2096 |
| 5 | 0.5 | 117 |
| 5 | 0.75 | 138 |
| 5 | 1 | 166 |
| 5 | 1.5 | 208 |
| 5 | 2.5 | 302 |
| 5 | 4 | 463 |
| 5 | 6 | 616 |
| 5 | 10 | 946 |
| 5 | 16 | 1315 |
| 7 | 0.5 | 138 |
| 7 | 0.75 | 167 |
| 7 | 1 | 198 |
| 7 | 1.5 | 251 |
| 7 | 2.5 | 379 |
| 7 | 4 | 588 |
| 7 | 6 | 792 |
| 12 | 0.5 | 213 |
| 12 | 0.75 | 272 |
| 12 | 1 | 316 |
| 12 | 1.5 | 414 |
| 18 | 0.75 | 367 |
| 18 | 1 | 441 |
| 18 | 1.5 | 569 |
| 25 | 0.75 | 569 |
| 25 | 1 | 611 |
| 25 | 1.5 | 818 |
