Applications:
MC Cable with Isolated Ground constructions are designed for applications where additional or redundant grounding conductors are required. MC Cable is suitable for use in branch, feeder and distribution circuits in commercial, industrial, institutional and multi-residential applications. MC Cable is approved for power, lighting, control and signal circuits. MC Cable can be used in cable tray and other approved raceways and can be exposed or concealed. MC Cable can be used in places of assembly of 100 people or more, such as studios and theaters. Voltage ratings should not exceed 600V in any application.
ASSEMBLY
Stranded or solid soft drawn bare copper conductors with polyvinyl chloride (PVC)/nylon THHN/THWN insulation, a green insulated ground and an isolated insulated ground with yellow stripes on green insulation, are cabled together with a Mylar tape
ARMOR:
Overall aluminum interlocked armor applied over the assembly. The temperature rating is 90°C dry
STANDARDS & REFERENCES
UL 83
UL 1569
UL 1685
UL Online Product Guide Info – Metal-Clad Cable (PJAZ)
Federal Specification A-A59544 (formerly J-C-30B)
FT4/IEEE 1202 (70,000 Btu/hr) Vertical Cable Tray Flame Test
NFPA 70 (National Electrical Code), Article 330
Listed for use in UL 1, 2 and 3 Hour Through Penetration Firestop Systems
REACH/RoHS-2 (Chemical Limit) Compliant
| CONDUCTOR SIZE AND COLORS | GROUNDING SIZE AND COLOR | WEIGHT (LBS/1000’) | OVERALL DIAMETER (INCHES) |
| SOLID CONDUCTOR COLORS 120/208V | |||
| 14-2 SOLID (BLACK/WHITE) | 14 SOLID (GREEN) | 77 | 0.439 |
| 14-3 SOLID (BLACK/WHITE/RED) | 14 SOLID (GREEN) | 94 | 0.464 |
| 14-4 SOLID (BLACK/WHITE/RED/BLUE) | 14 SOLID (GREEN) | 112 | 0.494 |
| 12-2 SOLID (BLACK/WHITE) | 12 SOLID (GREEN) | 105 | 0.475 |
| 12-2 SOLID (RED/WHITE) | 12 SOLID (GREEN) | 105 | 0.475 |
| 12-2 SOLID (BLUE/WHITE) | 12 SOLID (GREEN) | 105 | 0.475 |
| 12-3 SOLID (BLACK/WHITE/RED) | 12 SOLID (GREEN) | 129 | 0.505 |
| 12-3 SOLID (BLACK/WHITE/BLUE) | 12 SOLID (GREEN) | 129 | 0.505 |
| 12-3 SOLID (RED/WHITE/BLUE) | 12 SOLID (GREEN) | 129 | 0.505 |
| 12-4 SOLID (BLACK/WHITE/RED/BLUE) | 12 SOLID (GREEN) | 155 | 0.539 |
| 10-2 SOLID (BLACK/WHITE) | 10 SOLID (GREEN) | 150 | 0.542 |
| 10-2 SOLID (RED/WHITE) | 10 SOLID (GREEN) | 150 | 0.542 |
| 10-2 SOLID (BLUE/WHITE) | 10 SOLID (GREEN) | 150 | 0.542 |
| 10-3 SOLID (BLACK/WHITE/RED) | 10 SOLID (GREEN) | 189 | 0.58 |
| 10-4 SOLID (BLACK/WHITE/RED/BLUE) | 10 SOLID (GREEN) | 229 | 0.623 |
| STRANDED CONDUCTOR COLORS 120/208V | |||
| 12-2 STRANDED (BLACK/WHITE) | 12 STRANDED (GREEN) | 110 | 0.494 |
| 12-3 STRANDED (BLACK/WHITE/RED) | 12 STRANDED (GREEN) | 134 | 0.537 |
| 12-4 STRANDED (BLACK/WHITE/RED/BLUE) | 12 STRANDED (GREEN) | 164 | 0.564 |
| 10-2 STRANDED (BLACK/WHITE) | 10 STRANDED (GREEN) | 159 | 0.566 |
| 10-3 STRANDED (BLACK/WHITE/RED) | 10 STRANDED (GREEN) | 201 | 0.607 |
| 10-4 STRANDED (BLACK/WHITE/RED/BLUE) | 10 STRANDED (GREEN) | 242 | 0.653 |
| SOLID CONDUCTOR COLORS 277/480V | |||
| 12-2 SOLID (YELLOW/GRAY) | 12 SOLID (GREEN) | 105 | 0.475 |
| 12-2 SOLID (BROWN/GRAY) | 12 SOLID (GREEN) | 105 | 0.475 |
| 12-2 SOLID (ORANGE/GRAY) | 12 SOLID (GREEN) | 105 | 0.475 |
| 12-2 SOLID (PURPLE/GRAY) | 12 SOLID (GREEN) | 105 | 0.475 |
| 12-3 SOLID (BROWN/YELLOW/GRAY) | 12 SOLID (GREEN) | 129 | 0.539 |
| 12-3 SOLID (BROWN/ORANG/GRAY) | 12 SOLID (GREEN) | 129 | 0.539 |
| 12-3 SOLID (ORANGE/YELLOW/GRAY) | 12 SOLID (GREEN) | 129 | 0.539 |
| 12-4 SOLID (BROWN/ORANGE/YELLOW/GRAY) | 12 SOLID (GREEN) | 155 | 0.539 |
| 10-2 SOLID (ORANGE/GRAY) | 10 SOLID (GREEN) | 150 | 0.542 |
| 10-2 SOLID (YELLOW/GRAY) | 10 SOLID (GREEN) | 150 | 0.542 |
| 10-2 SOLID (BROWN/GRAY) | 10 SOLID (GREEN) | 150 | 0.542 |
| 10-3 SOLID (BROWN/ORANGE/GRAY) | 10 SOLID (GREEN) | 189 | 0.58 |
| 10-3 SOLID (BROWN/YELLOW/GRAY) | 10 SOLID (GREEN) | 189 | 0.58 |
| 10-4 SOLID (BROWN/ORANGE/YELLOW/GRAY) | 10 SOLID (GREEN) | 229 | 0.623 |
| STRANDED CONDUCTOR COLORS 277/480V | |||
| 12-2 STRANDED (YELLOW/GRAY) | 12 STRANDED (GREEN) | 110 | 0.494 |
| 12-2 STRANDED (BROWN/GRAY) | 12 STRANDED (GREEN) | 110 | 0.494 |
| 12-2 STRANDED (ORANGE/GRAY) | 12 STRANDED (GREEN) | 110 | 0.494 |
| 12-3 STRANDED (BROWN/YELLOW/GRAY) | 12 STRANDED (GREEN) | 134 | 0.537 |
| 12-3 STRANDED (BROWN/ORANGE/GRAY) | 12 STRANDED (GREEN) | 134 | 0.537 |
| 12-4 STRANDED (BROWN/ORANGE/YELLOW/GRAY) | 12 STRANDED (GREEN) | 164 | 0.564 |
| 10-2 STRANDED (BROWN/GRAY) | 10 STRANDED (GREEN) | 159 | 0.566 |
| 10-3 STRANDED (BROWN/ORANGE/GRAY) | 10 STRANDED (GREEN) | 201 | 0.607 |
| 10-4 STRANDED (BROWN/ORANGE/YELLOW/GRAY) | 10 STRANDED (GREEN) | 242 | 0.653 |
| INTERMEDIATE CONDUCTOR COLORS 120/208V | |||
| 8-2 STRANDED (BLACK/WHITE) | 10 STRANDED (GREEN) | 231 | 0.644 |
| 8-2 STRANDED (RED/WHITE) | 10 STRANDED (GREEN) | 231 | 0.644 |
| 8-2 STRANDED (BLUE/WHITE) | 10 STRANDED (GREEN) | 231 | 0.644 |
| 8-3 STRANDED (BLACK/WHITE/RED) | 10 STRANDED (GREEN) | 299 | 0.678 |
| 8-3 STRANDED (RED/BLUE/WHITE) | 10 STRANDED (GREEN) | 299 | 0.678 |
| 8-4 STRANDED (BLACK/WHITE/RED/BLUE) | 10 STRANDED (GREEN) | 378 | 0.793 |
| 6-2 STRANDED (BLACK/WHITE) | 8 STRANDED (GREEN) | 312 | 0.716 |
| 6-3 STRANDED (BLACK/WHITE/RED) | 8 STRANDED (GREEN) | 442 | 0.819 |
| 6-4 STRANDED (BLACK/WHITE/RED/BLUE) | 8 STRANDED (GREEN) | 546 | 0.89 |
| 4-3 STRANDED (BLACK/WHITE/RED) | 8 STRANDED (GREEN) | 635 | 0.986 |
| 4-4 STRANDED (BLACK/WHITE/RED/BLUE) | 8 STRANDED (GREEN) | 797 | 1.077 |
| 3-3 STRANDED (BLACK/WHITE/RED) | 6 STRANDED (GREEN) | 785 | 1.053 |
| 3-4 STRANDED (BLACK/WHITE/RED/BLUE) | 6 STRANDED (GREEN) | 985 | 1.152 |
| 2-3 STRANDED (BLACK/WHITE/RED) | 6 STRANDED (GREEN) | 936 | 1.13 |
| 2-4 STRANDED (BLACK/WHITE/RED/BLUE) | 6 STRANDED (GREEN) | 1195 | 1.239 |
| INTERMEDIATE CONDUCTOR COLORS 277/480V | |||
| 8-2 STRANDED (BROWN/GRAY) | 10 STRANDED (GREEN) | 231 | 0.644 |
| 8-2 STRANDED (YELLOW/GRAY) | 10 STRANDED (GREEN) | 231 | 0.644 |
| 8-2 STRANDED (ORANGE/GRAY) | 10 STRANDED (GREEN) | 231 | 0.644 |
| 8-3 STRANDED (BROWN/ORANGE/GRAY) | 10 STRANDED (GREEN) | 299 | 0.678 |
| 8-3 STRANDED (BROWN/YELLOW/GRAY) | 10 STRANDED (GREEN) | 299 | 0.678 |
| 6-2 STRANDED (BROWN/GRAY) | 8 STRANDED (GREEN) | 333 | 0.716 |
| 6-2 STRANDED (YELLOW/GRAY) | 8 STRANDED (GREEN) | 333 | 0.716 |
| 6-3 STRANDED (BROWN/ORANGE/GRAY) | 8 STRANDED (GREEN) | 441 | 0.819 |
| 6-3 STRANDED (BROWN/ORANGE/YELLOW) | 8 STRANDED (GREEN) | 441 | 0.819 |
| 6-4 STRANDED (BROWN/ORANGE/YELLOW/GRAY) | 8 STRANDED (GREEN) | 545 | 0.89 |
| 4-3 STRANDED (BROWN/ORANGE/YELLOW) | 8 STRANDED (GREEN) | 635 | 0.985 |
| 4-4 STRANDED (BROWN/ORANGE/YELLOW/GRAY) | 8 STRANDED (GREEN) | 800 | 1.076 |
| 2-3 STRANDED (BROWN/ORANGE/YELLOW) | 6 STRANDED (GREEN) | 921 | 1.034 |
| 2-4 STRANDED (BROWN/ORANGE/YELLOW/GRAY) | 6 STRANDED (GREEN) | 1181 | 1.238 |
| For allowable ampacities, refer to NEC 310.15. Available in sizes up to 750 kcmil. | |||
